Vectorizing images in Python for Machine Learning image classification

By


I'm doing the Astrozoo competition on Kaggle right now. The goal is to create an algorithm to accurately classify galaxies into different types. The training set is a zip file consisting of over 50,000 images. Before you do anything, the first step would be to convert the images into a usable format for analysis, such as resizing each image to 100x100 and converting it into a vector of data points. Here is the code I've pieced together to do that.

Running this code will convert all jpeg files in a specified folder into vectors and dump it into a .txt file.







#take all files in one directory and move it into another directory

import os
import glob #allows you to look at file names
import PIL #allows you to manipulate images (for resize)

#main script variables

orig_dir = '/home/luwei/Desktop/Dropbox/Kaggle/astrozoo/testing' #where the images are located
crop_dimensions = (140, 140, 284, 284) #dimensions to crop each image by
pixelsize = 5 #set size of pixels for the pixelate operation
vectorfile = '/home/luwei/Desktop/Dropbox/Kaggle/astrozoo/imagevectors.txt' #directory of vector output file



#change the directory to where the images are
os.chdir(orig_dir)


filenames = glob.glob("*.jpg") #store all the filenames into an array


#resize every image in the folder to
with open(vectorfile, 'wb') as outfile:
    for fileid in filenames:
        img = Image.open(fileid) #open the image
        img = img.crop(crop_dimensions) #crop each image
        img = img.resize((100,100)) #resize the image
        img = img.convert('L') #convert each image to grayscale
        ###pixelate the image###
        img = img.resize((img.size[0]/pixelsize,img.size[1]/pixelsize), Image.NEAREST) #reduce the size of the image by factor of 5
        img = img.resize((img.size[0]*pixelsize, img.size[1]*pixelsize), Image.NEAREST) #increase the size of the image by a factor of 5
        #########################
        pixel = img.load() #store pixel data in the pixel variable

        imagevector = [] #create an empty imagevector for each image
        u = 0 #marker for the pixel

        for x in range(0, img.size[0], pixelsize): #for every x coordinate in the pixel data of the image
            for y in range(0, img.size[1], pixelsize): #for every y coordinate in the pixel data of the image
                pixelvalue = pixel[x,y] #value of that particular pixel coordinate
                imagevector.append((u, (x, y), round(pixelvalue/float(255),3) ) ) #store pixel number, coordinate, and grayscale value (converted from 0 to 255 to a number between 0 and 1)into an array
                u = u + 1 #add one to the pixel marker

        vectorfile = open('imagevectors.txt', 'r+')
        outfile.write(str(fileid) + " " + str(imagevector) + "\n")
        print fileid

        #img.save('resized' + file + '.jpg')
